B-22221-012 | 12" Overall Width Tail Pulley

This 4" diameter crowned tail pulley fits the end of Hytrol TA conveyors with a 12" overall bed width (OAW). Designed for the non-driven end of the conveyor, this pulley helps guide the return belt and maintain tension.

Commonly used on Hytrol’s top-selling TA model.

• Pulley Diameter: 4"
• Shaft Diameter: 1" solid shaft
• Overall Conveyor Width (OAW): 12"
• Pulley Face Length: 10-7/8"
• Shaft Style: Solid 1" shaft extends 2-1/16" from each side
• Pulley Type: Crowned face to center belt tracking

📐 Technical Specifications
• Overall Shaft Length: 15"
• Pulley Face Length: 10-7/8"
• Overall Pulley Length (including shaft ends): 15"
• Shaft Style: Solid 1" diameter
• Installation: Bolts into tail of Hytrol TA conveyor frame

Helpful Tip: It’s recommended to replace bearings while replacing the pulley. Bearings can be added to your cart and purchased here.
